Description
Briggs Stratton 104M02 0197-F1 163cc Performance and value in one unbeatable package. You’ll love the smooth handling of the lightweight, yet powerful EX Series lawn mower engines. Equipped with the ReadyStart Starting System-no prime, no choke, just pull for power, a best-in-class torque-to-weight ratio, reduced vibration and quieter operation, all while increasing comfort and extending engine life. The EX Series Engines are a great solution to your lawn care challenges.n
Briggs Stratton 104M02 0197-F1 163cc Specifications
| BRAND | Briggs Stratton |
|---|---|
| MODEL NUMBER | 104M02-0197-F1 |
| WARRANTY | 2 Year Consumer / 90 Day Commercial |
| SHIPPING WEIGHT | 24 |
| DISPLACEMENT | 163cc |
| STARTER TYPE | Recoil |
| CRANKSHAFT ORIENTATION | Vertical |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 7/8″ x 3-5/32″ |
| CRANKSHAFT LENGTH | 3-5/32″ |
| CRANKSHAFT END TAPPED SIZE | 3/8 – 24 |
| CRANKSHAFT KEYWAY WIDTH | 3/16″ |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| BEARING TYPE | Plain |
| CYLINDERS | 1 |
| CYLINDER BORE TYPE | Aluminum Alloy |
| AIR CLEANER TYPE | Cartridge Type |
| FUEL TANK | Yes |
| FUEL PUMP | No |
| OIL COOLER | No |
| OIL CAPACITY | 15.2 |
| LOW OIL ALERT | No |
| IGNITION SYSTEM | Electronic |
| CARBURETOR TYPE | Float |
| CHOKE CONTROL | Ready Start |
| MAX RPM | 3200 |
| CHARGING SYSTEM | None |
| FLYWHEEL | Light |
| NOTES | Must add heavy flywheel, fan and control bracket for logsplitters and DR Trimmer mowers. |
| PTO HEIGHT | N/A |
