Description
Briggs Stratton 21R702 0070-F1 vertical OHV Intek engine is 344cc and puts out 10.5 gross HP. The single cylinder Briggs Stratton Intek has a 1″ x 3-5/32″ crankshaft. The engine has a recoil starter and includes a fuel tank, fuel pump and muffler. Briggs Stratton Intek series engines deliver the reliable, efficient power needed for riding lawn mowers and tractors. Buyer protection package provides a two-year limited consumer warranty. 50-State CARB Compliant. All engines purchased from us ship for free and are foam packed for added protection during transit. This engine replaces model 217902-40.
Briggs Stratton 21R702 0070-F1 vertical OHV Intek engine Key Specifications
| BRAND | Briggs Stratton |
|---|---|
| MODEL NUMBER | 21R702-0070-F1 |
| REPLACES MODELS | 217902-4020-F1, 217902-4020, 217902-0020-B1, 217902-0020, 216902-0020-E1, 216902-0020, 215902-0020-B1, 215902-0020, 215902-0020-E1, 212902-0020-E1, 212902-0020, |
| WARRANTY | 2 Year Consumer / 1 Year Commercial |
| SHIPPING WEIGHT | 69 |
| DISPLACEMENT | 344cc |
| STARTER TYPE | Recoil |
| CRANKSHAFT ORIENTATION | Vertical |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 1″ x 3-5/32″ |
| CRANKSHAFT LENGTH | 3-5/32″ |
| CRANKSHAFT END TAPPED SIZE | 7/16 – 20 |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| BEARING TYPE | Plain PTO |
| CYLINDERS | 1 |
| CYLINDER BORE TYPE | Cast Iron Sleeve |
| AIR CLEANER TYPE | Cartridge Type |
| FUEL TANK | Yes |
| FUEL PUMP | Yes |
| OIL COOLER | No |
| OIL CAPACITY | 48 |
| LOW OIL ALERT | No |
| LOW OIL SHUTDOWN | No |
| IGNITION SYSTEM | Electronic |
| CARBURETOR TYPE | Float |
| CHOKE CONTROL | Choke-A-matic |
| MAX RPM | 3400 |
| CHARGING SYSTEM | None |
| BOLT CIRCLE | 10″ |
| FLYWHEEL | Heavy |
| NOTES | Engine Notes: |
| PTO HEIGHT | N/A |
