Description
Kawasaki FJ180V-M09-S 179cc, 6 HP, vertical, OHV, 4-cycle single-cylinder engine. This FJ180V KAI engine has a 25mm x 3-5/32″ (80mm) crankshaft, a recoil starter and low tone muffler with guard. A fuel tank is not included with this engine. With features like pressurized lubrication and ball bearing supported crankshafts, Kawasaki FJ Series engines deliver reliable power while keeping the operator comfortable. Buyer protection package provides a three-year engine warranty. 50-State CARB Compliant. All engines purchased from us ship for free and are foam packed for added protection during transit
Key Specifications
| BRAND | Kawasaki |
|---|---|
| MODEL NUMBER | FJ180V-BM09-S |
| WARRANTY | 3 Year Limited |
| SHIPPING WEIGHT | 30 |
| DISPLACEMENT | 179cc |
| STARTER TYPE | Recoil |
| CRANKSHAFT ORIENTATION | Vertical |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 25mm x 3-5/32″ |
| CRANKSHAFT DIAMETER | 25mm |
| CRANKSHAFT LENGTH | 3-5/32″ |
| CRANKSHAFT END TAPPED SIZE | 3/8 – 24 |
| CRANKSHAFT KEYWAY WIDTH | 3/16″ |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| BEARING TYPE | Ball |
| CYLINDERS | 1 |
| CYLINDER BORE TYPE | Cast Iron Sleeve |
| AIR CLEANER TYPE | Dual Element |
| FUEL TANK | No |
| FUEL PUMP | No |
| OIL COOLER | No |
| LOW OIL ALERT | No |
| IGNITION SYSTEM | Flywheel Magneto Transistor |
| CARBURETOR TYPE | Internally Vented |
| MAX RPM | 3600 |
| BOLT CIRCLE | 8 |
| NOTES | Engine Notes: |
| PTO HEIGHT | N/A |
